Place of Origin:
Sichuan
Brand Name:
DUKE
Certification:
ISO 9001:2008/EN263
Model Number:
Custom Cutting
Production Introduction
| Products Type | Clear acrylic sheet |
| Size(mm) | 1220*2440,1220*1830,2050*3050,2000*3000/Customized |
| Thickness | 1.8mm-50mm |
| Density | 1.2kg/cm3 |
| Color | Transparent, white, opal, blue, red,yellow ect. / As your requirement |
| Light transmission | 92% |
| MOQ | 100Pieces / negotiable |
| Material | 100% virgin Mitsubishi MMA | ||
| Item | Test Result | Item | Test Result |
| Transmittance% | 92% | Tensile Strain | ≥70 MPa |
| Modulus of Elasticity | ≥3100MPa | Specific Gravity | 1.19 |
| Vicat Softening Temperature | ≥110℃ | Rockwell Hardness(R) | 95 |
| Bending Strength | ≥98MPa | Elongation at Break | 4% |
| Water Absorption | 0.30% | Compressive Strength | 130MPa |
Feature
1. It has crystal-like transparency, the light transmittance is above 93%, the light is soft, the vision is clear, and the acrylic colored with dyes has a good color development effect.
2. Acrylic sheet has excellent weather resistance, high surface hardness and surface gloss, and good high temperature performance.
3. Acrylic sheet has good processing performance, which can be thermoformed or mechanically processed.
4. The transparent acrylic sheet has a light transmittance comparable to that of glass, but the density is only half of that of glass. Also, it is not as brittle as glass, and even if it breaks, it does not form sharp shards like glass.
5. The wear resistance of acrylic plate is close to that of aluminum, with good stability and corrosion resistance to various chemicals.
6. The acrylic sheet has good sprayability, and the appropriate printing and spraying process can give acrylic products an ideal surface decoration effect.
7. 20 m vertical gravity conveying design ensures good quality and efficient production.
8. Multilayer special leach to eliminate the possible incorporation of impurities.
9. Smart mechanical stripping transport, to ensure perfect quality show.
10. The International technical, advanced equipment,combined with highly valid team.
How To Distinguish Recirculating Panel
1.Recirculating panel is yellow in its appearance especially the cross section.most have bubbles and spots.
2.The thickness and hardness of recirculating panel is not even and easy to be scratched.
3.Recirculating panel bring peculiar smell while machining and stroage.
4.Recirculating panel is easilu to be distorted when heated in high temperature.
5.Sensitive to oil painting and easilu to be dehisced.
6.Poor anti UV performance and easilu to be yellowing and deforming.
7.Poor anti corrosion performance.
Chengdu Cast Acrylic Panel Co.,Ltd(CDA) is the wholly owned subsidiary of Monarch Group relies on the industry-leading technical support of Mitsubishi Rayon Co.,Ltd,CDA produced acrylic sheet named Brand DUKE.CDA is a company intergrating R&D,productio,manufacturing and sales and it is in absolute leading position of the domestic PMMA industry.Product wild used in sanitary,AD sign,aquarium board,noise barrier board,etc.
Founded in 2007,covers an area of 52000 square meters,total investment of 120 million.Factory layout and facilities are all in accordance with the world's leading standard,with two of the world advanced level cast production lines,Annual capacity can reach to 10000 tons per year.Using 100% pure new Mitsubishi MMA material ,English Pilkington Mould and imported color paste to insure manufacture the high qualitu carylic sheets.
Q1: Whether the raw material is brand new
A1: Because we have been a partner of Mitsubishi Rayon for many years, we have promised to use only 100% pure new Mitsubishi MMA
Q2: Product tolerance
A2: The product adopts the world-class casting process, and we control the tolerance within 0.2mm
Q3: Product impurities
A3: The whole workshop of the company has strict environmental hygiene standards, multilayer special filter to eliminate the possible incorporation of impurities . we will carry out strict inspection for each batch of products, to ensure that the quality of each batch is the same
Q4: Product color
A4: We have 60 colors to choose from. If you need to customize, please specify in advance
Q5: MOQ
A5: MOQ: 2000 kg
